Highlights

  • Designed for Education
  • 0.35, 1.3, 2.1 and 5.1 mega pixel versions
  • Educational PC software
  • Easy to operate
  • Can be used in combination with android phones
Models
Specifications
Downloads

Models

Product number Models Pixels (Mp) Sensor (inch) Pixel size (μm) Exposure time Max. frames (p/sec) Resolution Grayscale conversion Sensitivity mV/lux-sec Signal/ Noise (db) Dynamic (db)
DC.0350E Explorer Go! 0.35 1/4 5.6 x 5.6 Auto 30 640 x 480 8 bit 1350 42 79
DC.1300E Explorer 1 1.3 1/3 3.41 x 3.41 0.1-2000 ms 38 1520 x 856 8 bit 4510 38.5 74
760 x 428
DC.2100E Explorer 2 2.1 1/2.8 2.9 x 2.9 0.1-2000 ms 30 1920 x 1080 8 bit 1300 43 73
960 x 540
DC.5100E Explorer 5 5.1 1/2.5 2.2 x 2.2 0.1-1000 ms 30 2592 x 1944 8 bit 1880 40 73
1280 x 960
640 x 480

• Interactive tutorial on the camera, compound and stereo microscopes and their functions

CMEX-Explorer-1

• Image based instructions on how to make specimen slides

CMEX-Explorer-2

• A photo editor that lets users view and edit images taken with the camera. Includes editing tools for writing notes on an image, cropping it and adding fun stamps or arrows. Select an image or a part of it to save, send by e-mail or even include it in a report

CMEX-Explorer-3b

CMEX-Explorer-3a

• Includes a library of samples of plants, insects and animals

CMEX-Explorer-5

• A personal library to store new images in

CMEX-Explorer-4
